BIC Ganglia Setup

Some doc here http://www.ibm.com/developerworks/wikis/display/WikiPtype/ganglia

Server

/etc/ganglia/gmetad.conf (:source:) data_source “BIC Xen” matsya gridname “BIC” authority “http://matsya.bic.mni.mcgill.ca/ganglia case_sensitive_hostnames 1 (:sourceend:)

Client

/etc/ganglia/gmond.conf (:source:) cluster {

 name = “BIC Xen”
 owner = “unspecified”
 latlong = “unspecified”
 url = “unspecified”

}

udp_send_channel {

 mcast_join = 239.2.11.71

1. mcast_join = 132.206.178.240

 port = 8649
 ttl = 1

}

udp_recv_channel {

 mcast_join = 239.2.11.71
 port = 8649
 bind = 239.2.11.71

}

tcp_accept_channel {

 port = 8649

} (:sourceend:)

Web Front-End

/etc/apache2/sites-enabled/000-default (:source:) <VirtualHost *:80>

       ServerAdmin webmaster@localhost

…

   <Directory “/usr/share/ganglia-webfrontend/”>
               Options Indexes FollowSymLinks MultiViews
               AllowOverride None
               Order deny,allow
               allow from 132.206.178.
   </Directory>

</VirtualHost> (:sourceend:)
